Scan QRCode on EasyAccess 2.0 page in HMI system setting or project to start configure push notification to social media accounts (Facebook, Line, WeChat)
To configure QRCode in EasyBuilder Pro, select Object => Barcodes => WeChat Barcode Display
After scan QRCode via your mobile phone. Click to subscribe push notification to your social media account
Send Message to Facebook fans page, follow instructions and receivce push notification from HMI
Click 'HMI list' in Facebook Messenger to configure HMI settings
Select chat (chat room or one by one chat) to receive HMI push notification
If you select chat room at previous step. To receive HMI push notification, please remember to add 'Line Notify' to the chat room
After subscription success. You will receive HMI push notification from Line Notify
Notification settings can be edited via link in message
Use "Scan" in WeChat to scan QRCode
"Follow" public account "EasyAccess V2" to receive HMI push notification
Click "Manage" to manage HMI
Domain admin can manage these relationships in Notification tab (https://account.ihmi.net/domain/Default.php)
We are proud to announce that EasyAccess 2.0 service has passed security assessment and proven to be safe.
A third-party security firm has verified and checked our EasyAccess 2.0.
We also broadly reviewed the security of EasyAccess 2.0 and enhanced several minor risks.
To see more details, go to Security Certificate.
(a) On the list of HMI, click on the “Pass-through” icon which appears below the IP address when connection in active.
(b) Enter the IP address of the target PLC. Support up to 6 IP addresses.
(a) In domain management web page (https://account.ihmi.net/domain), under the “Devices” tab, click “HMI Folder View”. HMI can be managed easily by creating your own folder/category. In this page, the Domain Admin can: Add/Edit/Delete folders, or Move hmi/folder to another folder. For domains with a large number of HMIs, search tool is also available.
List of Folders and HMIs
The Domain Admin can create a new folder in this domain.
Current folder levels is displayed above the table. Click folder name to go to a different level of folder.
Operation toolbar will be shown via selecting folder.
Edit foder name.
Delete selected folders.
Move folders or HMIs to specific folder.
Move to folder
|Search for a folder or HMI.|
(b) The folder structure also displayed on EasyAccess 2.0 Application
Folder Structure on EasyAccess 2.0 (Windows)
Folder Structure on EasyAccess 2.0 (Mobile)
Click user icon to select Activity report operation. Subscribe the report and select schedule. The report will be sent to domain admin email according to schedule (Daily, Weekly, Monthly). You can also send test report to see if it works by clicking 'Send a copy now (1d.)'.
In domain page, under the “Wechat” tab, click “Wechat Users” to manage HMIs according to wechat account. click “HMI Management” to management wechat account according to HMI
Wechat Users Management
You may enter FTP password beforehand and copy the FTP URL when you long press, right click on the VPN IP, or click the copy button next to 'Password in FTP URL'
